| Price | $1 |
|---|---|
| Category | Others |
| Availability | In stock |
| Delivery | Shipped across Lebanon, or collect from the lab |
A mini solderless breadboard, 47 x 35 mm, with 170 tie-points laid out as 17 rows of five-and-five either side of the centre channel. There are no power rails, so it suits one small circuit, a sensor breakout or a single 14- or 16-pin DIP chip. Adhesive backing and two mounting holes let you fix it inside a project, and the side tabs clip onto another board when you need more room.
Key features
- 170 tie-points in 17 rows, no power rails
- 47 x 35 mm - fits inside small enclosures
- Standard 2.54 mm pitch, solderless
- Adhesive backing plus two mounting holes
- Side tabs clip boards together
Details
Specifications
| Type | Solderless breadboard |
|---|---|
| Tie-points | 170 |
| Rows | 17 |
| Power rails | None |
| Dimensions | 47 x 35 mm |
| Pitch | 2.54 mm |
| Capacity | Up to two 14- or 16-pin DIP ICs |
| Mounting | Adhesive backing, 2 mounting holes, interlocking tabs |
