| Price | $4 |
|---|---|
| Category | Shields |
| Availability | In stock |
| Delivery | Shipped across Lebanon, or collect from the lab |
A two-piece screw-terminal set that clips onto the Uno's two header rows and leaves the middle of the board open, so it adds almost no height. Between the pair you get terminals for the lot - D0 to D13, GND and AREF plus SDA and SCL on one wing, and IOREF, RESET, 3V3, 5V, GND, VIN and A0 to A5 on the other. Female headers run alongside so other shields can still stack on top.
Key features
- Supplied as a matched pair of wings, one per header row
- Terminals for D0-D13, GND, AREF, SDA and SCL
- Terminals for IOREF, RESET, 3V3, 5V, GND, VIN and A0-A5
- Pass-through female headers keep the Uno stackable
- Leaves the centre of the Uno clear - very low profile
- Covers the R3 pins, unlike older screw shields
Details
Specifications
| For | Arduino Uno (R3 pinout) |
|---|---|
| Type | Two-piece screw-terminal wing set |
| Terminals | All digital, analogue and power pins, plus SDA / SCL / IOREF |
| Headers | Female pass-through headers on both wings |
| Supplied as | Pair of boards |
