| Price | $3 |
|---|---|
| Category | Others |
| Availability | In stock |
| Delivery | Shipped across Lebanon, or collect from the lab |
The full-size MB-102 breadboard, 165 x 55 x 10 mm with 830 tie-points - 630 in 63 component rows and 200 more in the four power rails running down both sides. That is enough room for a microcontroller, several DIP chips and their support parts on one board. It takes solid wire from about 20 to 29 AWG and has adhesive backing if you want to fix it down.
Key features
- 830 tie-points - 630 component, 200 power rail
- 63 rows, four power rails marked + and -
- 165 x 55 x 10 mm ABS body
- Takes 20-29 AWG solid wire
- Adhesive backing and interlocking tabs
Details
Specifications
| Model | MB-102 |
|---|---|
| Type | Solderless breadboard |
| Tie-points | 830 |
| Terminal strip | 630 points, 63 rows |
| Power rails | 4 (200 points) |
| Dimensions | 165 x 55 x 10 mm |
| Pitch | 2.54 mm |
| Wire size | 20-29 AWG |
