| Price | $3 |
|---|---|
| Category | Actuators & Drivers |
| Availability | In stock |
| Delivery | Shipped across Lebanon, or collect from the lab |
A self-priming pump built on the RS-360SH motor with a plastic pump head - unlike a submersible, it sits outside the tank and sucks water up to itself, so it can empty a container or push liquid round a loop. It runs anywhere from 3 to 12V (5V at 2A is the sweet spot), gives around 0.5 L/min with a head of up to about 1.5 m, and the 4 mm inlet and outlet take small silicone tubing. Reverse the supply polarity and the flow reverses with it.
Key features
- Self-priming - mounts outside the water
- Runs on 3-12V DC, 5V at 2A recommended
- Approx. 0.5 L/min flow, up to about 1.5 m head
- 4 mm inlet and outlet barbs
- Reverse the polarity to reverse the flow
- 60 mm long, 44 mm pump head, 27 mm motor
Details
Specifications
| Model | RS-360SH motor with plastic pump head |
|---|---|
| Type | Self-priming DC water pump (not submersible) |
| Operating voltage | 3-12V DC |
| Recommended supply | 5V at 2 A |
| Current draw | approx. 1.15 A at 6V |
| Flow rate | approx. 0.5 L/min (about 30 L/h) at 5V |
| Max head | up to approx. 1.5 m |
| Inlet / outlet | 4 mm |
| Body size | 60 mm long, 44 mm pump head dia., 27 mm motor dia. |
| Reversible | Yes - swap polarity to swap inlet and outlet |
