A fast-recovery rectifier: same 1000 V blocking as a 1N4007 but rated 1.5 A and, more to the point, it stops conducting in about 500 ns instead of tens of microseconds. That is what makes it usable as the output or freewheel diode in a switching supply, an inverter or a boost converter, where an ordinary rectifier would sit there conducting backwards and cooking. Axial DO-15 body, banded end is the cathode.
Key features
- Reverse recovery 500 ns
- 1.5 A average forward current at 55 C
- 1000 V repetitive peak reverse voltage
- Forward drop 1.3 V max at 1.5 A
- 50 A surge for one 8.3 ms half-cycle
- For SMPS, inverters and freewheel duty
Details
Specifications
| Model | FR157 |
|---|---|
| Type | Fast-recovery silicon rectifier |
| Package | DO-15 axial |
| Peak reverse voltage | 1000 V |
| RMS voltage | 700 V |
| Average forward current | 1.5 A at 55 C |
| Peak surge current | 50 A (8.3 ms half sine) |
| Forward voltage | 1.3 V max at 1.5 A |
| Reverse recovery time | 500 ns |
| Junction capacitance | 20 pF typ |
| Operating temperature | -55 C to +150 C |
