A general-purpose PNP transistor in TO-92 that handles rather more than the usual small-signal types: 800 mA of collector current, 45 V, and a gain of 100 to 630 at 100 mA. Being PNP it is the high-side switch - emitter to the positive rail, base pulled down through a resistor to turn it on - which is exactly what you want for switching a small load's supply from a microcontroller. Its NPN partner is the BC337.
Key features
- PNP - turns on when the base is pulled low
- 800 mA continuous collector current
- 45 V collector-emitter, 50 V collector-base
- Gain 100-630 at 100 mA, 40 minimum at 300 mA
- Saturation 0.7 V max at 500 mA
- TO-92, pins collector / base / emitter
- NPN complement is the BC337
Details
Specifications
| Model | BC327 |
|---|---|
| Type | PNP small-signal / medium-current transistor |
| Package | TO-92 |
| Collector-emitter voltage | -45 V |
| Collector-base voltage | -50 V |
| Emitter-base voltage | -5 V |
| Continuous current | -800 mA |
| Power dissipation | 625 mW |
| DC current gain | 100 to 630 at -100 mA; 40 min at -300 mA |
| Saturation voltage | -0.7 V max at -500 mA, base -50 mA |
| Transition frequency | 260 MHz |
| Pinout | 1 collector, 2 base, 3 emitter |
